Shimano 105 BR-R7010 Direct Mount Rim Brake

badge
badge
badge
badge

IBRR7010F82L

Sale price Rs. 4,670.00
/
Tax included. Shipping calculated at checkout.

Side

Shimano 105 BR-R7010 direct mount rim brake - more aerodynamics and tyre clearance

The Shimano 105 rim brake BR-R7010 for direct mount is mounted directly on the fork or the rear triangle (chainstays or seatstays). The main advantages of this type of mount are more aerodynamics, a cleaner appearance and even an increase in braking power. The brake offers space for tyres up to 28 mm wide and, thanks to SLR-EV technology, offers convincing performance that can be easily adjusted. Angle-adjustable cartridge brake shoes with R55C4 brake pads complete the package.

Specifications:

Series: 105 R7000
Application: Road, Triathlon & Time Trial
Type: dual pivot side-pull brakes
Mount: Direct Mount

Technical Information:

Material: aluminium
Surface Finish: anodised
Pads: R55C4 (standard; R55C4 carbon, R55C4-A carbon, R55CT4 optional)
Brake Arm Length: 51 mm
Actuation: brake cable

Approved For:

Tyre Size (max.): 28 mm (28c)
Rim Width (max.): 20.8 - 28 mm

Adjustment Options:

- brake shoe angle adjust
- spring tension adjust (only BR-R7010-R)

Features:

- front: direct fork mount
- rear: direct chainstay or seatstay mount
- clear contact feeling with balanced relationship between stiffness, weight and braking force
- slim design with a smaller gap between the brake arms
- more space for wider tyres
- cartridge brake shoes made of aluminium (painted)
tyre protectors
- quick release (not on BR-R7010-R)
- cable adjuster and quick release SM-CB90 available separately

Note from the manufacturer: When caliper is fully closed without rear wheel, the length of brake outer casing should be long enough between cable outer stopper and caliper.

Technology:

Dual Pivot
Dual pivot technology results in weight-saving, compact and robust brakes. In particular, the brakes from Dura Ace, Ultegra, 105 and Sora now offer maximum torsional stiffness and maximum load capacity with minimum tolerances. They respond precisely and without delay and their service life is significantly longer. In addition, Dura Ace, Ultegra and 105 brake pads are 100% more durable, allowing the rider to maintain the high performance of the brakes for longer.

SLR-EV
SLR-EV is a revised SLR with symmetric dual pivot side-pull brakes. A short-arm brake design uses two bearings and a roller to achieve greater efficiency in the joint area and provide superior modulation and force when braking.

Models:

Front:
Mount: forks
Type: BR-R7010-F
Manufacturer Part Number: I-BRR7010F82L

rear:
Mount: chainstays
Type: BR-R7010-R
Manufacturer Part Number: I-BRR7010R82L

rear seatstays:
Mount: seatstays
Type: BR-R7010-RS
Manufacturer Part Number: I-BRR7010RS82L

Contents:

- 1 x Shimano 105 rim brake, BR-R7010-F or BR-R7010-R or BR-R7010-RS
- 1 pairs of R55C4 brake pads


Weight:

  • silky black/front: 174 g
  • silky black/rear: 173 g
  • silky black/rear seatstays: 174 g
